Portable Ten-Print Biometric
Enrollment Terminal For High-Accuracy Identification
FBI Appendix-F & Mobile ID FAP 60 certified multi-fingerprint capture with a 2.0GHz processor. Built for high-volume enrollment where compliance and capture quality are essential.
Certified Capture. Large-Scale Readiness
Built for agencies conducting national ID, voter registration, and border security enrollment operations.
500 DPI optical sensor with large 3.2” * 3.0” platen supports flat four-finger and two-thumb capture.
ARM Cortex A53 @2.0GHz Quad-Core processor with 4GB RAM ensures fast biometric acquisition and template handling.
Auto capture with integrated NIST quality checks produces ISO/IEC 19794-4 compliant outputs.
32GB internal storage with Micro SD expansion upto 256GB supports extensive enrollment records.
How MOXA 7E Supports Your Operations
From structured enrollment drives to secure verification programs, MOXA 7E delivers certified biometric capture and dependable performance.
1600*1500 pixel fingerprint images with 8-bit grayscale depth enable detailed multi-finger acquisition.
2.0GHz Quad-Core processor with 4GB RAM ensures uninterrupted enrollment and biometric handling.
Dual Micro SIM 4G, Wi-Fi (2.4GHz & 5GHz), Bluetooth 5.0, Ethernet, and GPS enables flexible synchronization across environments.
Designed for easy upkeep with reliable performance and dedicated technical support for continuous operations.
Precision Engineering Inside Out
- OS: GMS Certified Android / Customized Android
- Processor: ARM Cortex A53 @2.0GHz Quad-Core
- Memory: 4GB RAM
- Storage: 32GB eMMC
- Expandable: Micro SD up to 256GB
- Fingerprint: Optical Scratch-Free FAP 60 Sensor
- Resolution: 500 DPI ±1%
- Active Platen Area: 3.2" x 3.0"
- Image Size: 1600 x 1500 Pixels
- Rear Camera: 8MP AF + High-Brightness LED
- Protection: IP65
- Operating Temperature: 0°C to 45°C
- Weight: Approx. 2.2kg
- Dimensions: 370 x 141 x 121 mm
- Battery: 9600mAh Li-Ion (Replaceable)
- Network: 2G / 3G / 4G LTE
- Wi-Fi: IEEE 802.11 a/b/g/n/ac
- Bluetooth: BT + BLE 5.0
- SIM: Dual Micro SIM
- USB: USB 2.0 Type-A
From Manual to Modern: Biometric SIM Registration in Nigeria
A leading Nigerian telecom company transformed SIM registration using Mantra's Moxa biometric handheld terminals. With 20,000+ Android-integrated devices, they now capture 80,000+ subscriber records daily surpassing 20 million biometric registrations. The result: faster onboarding, stronger fraud prevention, and a better experience for every customer.
Field Applications
Frequently Asked Questions
Yes. It supports flat four-finger and two-thumb capture with FBI FAP 60 certification.
Yes. With 4GB RAM, 32GB storage, and expansion up to 256GB, it supports sustained biometric operations.
Yes. It operates under direct sunlight up to 100K LUX and includes IP65 protection.
